Technical Specication

• Vacuum Chamber Dimensions : 748 mm x 565 mm x 112 mm
• Sealing Length : 687 mm
• Sealing Width : 5 mm
• Power : 220v AC / 440v AC (890w)
• Vacuum Pump : 500 LPM
• Air Charging Volume For -Vacuum Pump : 30 M³ / H
• Body Build Material : All Stainless Steel Food Grade
• Chamber Material : Cast Aluminium
• Machine Dimensions : 1602 mm x 613 mm x 637 mm
• Packing Cycle : 1 To 6 Cycle / Min (Depend on Product)
• Sealing Position of Vacuum -Chamber : Two (Per Chamber)
• Distance : 440 mm (Between Two Separate Sealing Bar)
• Electrical Material : Digital Electronic Control

Features

• To Product After Packing Can Be Prevented From Oxidation, Going Mould, Insects Or Getting Damp, Thus Can Be Kept Fresh For A Longel Time
• Double Chamber Vacuum Packaging Can Finish The Whole Programs Of Vacuum Extraction, Gas Flushing (Optional),Sealing, Cooling & Exhaust Automatically.
• To Observe Packaging All Process From The Top of The Transparent Acrylic Glass.
• Noise Free Operations.
• Easy To Adjust The Tray.

Applications

• Solid And Semi Liquid Product.
• Vacuum Is Also Available With Nitrogen Flushing.
